HSH-320/450/570/660/850/950 Flexographic Printing Press
HSH-320/450/570/660/850/950 Flexographic Printing Press

Automatic Flexo Printing Presses

Model: HSH-320/ 450/ 570/ 660/ 850/ 950

label printer sticker machine: Single servo motor for each printing station , it has the characteristics of fast speed, stable registration and easy operation.

Online Inquiry
Product
Description

This flexographic label printing machine adopts the latest lnovance servo system, the whole machine has 13 servo motors to control (8 colors 1 die cutting for example), equipped with web monitoring, turn and so on. It is the best choice for printing high-grade commercial labels.

flexographic label printing machine uses PS plate intermittent offset printing (web offset printing), which is very suitable for small batch and large batch production of high-end labels. It adopts advanced German three-point suspension pressure structure. The printing unit adopts high-quality heavy-duty offset printing unit. The advanced ink system effectively prevents ink staining and ghosting, significantly improving printing quality, accuracy and clarity.

The registration system allows the horizontal and vertical movement of each printing unit to be adjusted using independent servo motors. Print quality and productivity are greatly improved through static surface monitoring (standard) and continuous adjustment of horizontal and vertical register on the control panel.

A high-precision computer photoelectric tracking device is used to ensure accurate printing registration on the surface and back, expanding the range of label printing possibilities.

Technical
Parameters
Model HSH-320/450/570/660/850/950
Max.Speed 130m/min
Max.Web 320mm
Max.Printing width 310mm
Printing Perimeter 177.8mm - 368.3mm (56T-116T)
Max.Unwinding 1200mm
Max.Rewinding 1200mm
Registration accuracy ±0.15mm
Webguiding accuracy ±0.02mm
Thickness of plate 1.7mm/1.14mm
Thickness of tape 0.38mm
Voltage 380 V (50 Hz, 3 phases]*⁵
Power of IR dryer 4.0 KW/unit
Air Pressure 0.6-0.8 MPA
